6mm Koudgewalste Naadloze Staalbuis voor Automobielstructuren
Basis eigenschappen
Plaats van herkomst:
China
Merknaam:
New Era
Certificering:
ISO9001, ISO14001, TS16949
Modelnummer:
ASTM A519, EN 10297-1, JIS G3445
Handelsgoederen
Minimale bestelhoeveelheid:
1 ton
Prijs:
Onderhandelbaar
Betalingsvoorwaarden:
T/T
Leveringscapaciteit:
2000 ton/maand
Productoverzicht
Naadloze Staalbuis voor Automobielstructuren Ronde van de precisie de Koudgetrokken Naadloze Koolstof Materiaal: 1010, 1020, 1026,1045, 4130, STKM11A, STKM12B, E235, E255, E355 ENZ. Grootte: OD: 6mm~168mm GEWICHT: 1mm~30mm Lengte: maximum 11.8m, of cutted Techniek: De koude trekt/walste koud ...
Productdetails
Markeren:
Koudgewalste Naadloze Staalbuis 6mm
,De automobielbuis van het Structuren Naadloze Staal
,SAE1026 naadloze Koudgetrokken Staalbuis
Product Name:
Koolstofstaalbuis
OD Size:
6168mm
WT Size:
1-30mm
Steel Material:
SAE1020, SAE1026, SAE4130, STKM13A, STKM13B
Application:
Voor Autodelen, Machinesdelen
Delivery Time:
45 Dagen
Productbeschrijving
Naadloze Staalbuis voor Automobielstructuren
Ronde van de precisie de Koudgetrokken Naadloze Koolstof
Materiaal: 1010, 1020, 1026,1045, 4130, STKM11A, STKM12B, E235, E255, E355 ENZ.
Grootte: OD: 6mm~168mm GEWICHT: 1mm~30mm Lengte: maximum 11.8m, of cutted
Techniek: De koude trekt/walste koud
Oppervlakte: Antiroestolie
Beëindigenbeschermer: Plastic Pijp GLB
Tolerantie: Het kan binnen OD/Thickness +/-0.1mm worden gecontroleerd
Toepassing: Autodelen, Machinesdelen
Test: Spanningstest, die Test, Flenstest, Omgekeerde Test, van de Hardheidstest, Hydrostatische of Niet-destructieve Elektrische Test flakkeren
| Norm | Rang | Chemische Samenstelling (% gew.) | ||||||||
| C | Si | Mn | P | S | Cu | Ni | Cr | Mo | ||
| ASTM A519 | SAE 1020 | 0.18-0.23 | / | 0.30-0.60 | ≤0.040 | ≤0.050 | / | / | / | |
| SAE 1030 | 0.28-0.34 | 0.60-0.90 | ≤0.040 | ≤0.050 | ||||||
| SAE 1045 | 0.43-0.50 | / | 0.60-0.90 | ≤0.040 | ≤0.050 | / | / | / | / | |
| SAE 1524 | 0.19-0.25 | 1.35-1.65 | ≤0.040 | ≤0.050 | ||||||
| SAE 1541 | 0.36-0.44 | / | 1.35-1.65 | ≤0.040 | ≤0.050 | / | / | / | / | |
| SAE 4140 | 0.38-0.43 | 0.15-0.35 | 0.75-1.00 | ≤0.040 | ≤0.040 | 0.80-1.10 | 0.15-0.25 | |||
| EN 10297-1 | E275 | ≤0.21 | ≤0.35 | ≤1.40 | ≤0.030 | ≤0.035 | / | / | / | / |
| E315 | ≤0.21 | ≤0.30 | ≤1.50 | ≤0.030 | ≤0.035 | / | ||||
| E355 | ≤0.22 | ≤0.55 | ≤1.60 | ≤0.030 | ≤0.035 | |||||
| 41Cr4 | 0.38-0.45 | ≤0.40 | 0.60-0.90 | ≤0.035 | ≤0.035 | 0.90-1.20 | ||||
| 34CrMo4 | 0.30-0.37 | ≤0.40 | 0.60-0.90 | ≤0.035 | ≤0.035 | / | 0.15-0.30 | 0.90-1.20 | ||
| 42CrMo4 | 0.38-0.45 | ≤0.40 | 0.60-0.90 | ≤0.035 | ≤0.035 | / | 0.15-0.30 | 0.90-1.20 | ||
| JIS G3445 | STKM13A | ≤0.25 | ≤0.35 | 0.30-0.90 | ≤0.040 | |||||
| STKM13B | ≤0.25 | ≤0.35 | 0.30-0.90 | ≤0.040 | / | |||||
Het product toont
Markeringen: Naadloze Staalbuis, Automobielbuis, automobielstructurenbuizen, de Naadloze buis van het Precisiestaal, ASTM A519, JIS G3445
